First, the principle of automatic straightening machine:

?

Fully automatic straightening machine will need to straighten the end of the tube (rod) material into the center of the two rounds, through the motor, multi-gear reducer (frequency control), pulley, chain of bilateral synchronous drive, drive roller forward , Complete the straightening straightening straightening of the workpiece. Automatic Straightening Machine Main Uses: This equipment is suitable for the straightening of metal pipe (rod) material (there is a certain effect of calendering.

Second, the automatic straightening machine Product parameters:

Name: Automatic Straightening Machine

Product use: This equipment is suitable for metal pipe (rod) straightening processing has a certain calendering, pressure round effect

Product Technology: 15 years Taiwan brand

Weight: 5000kg

Roller: Ф120 × 150 14 groups

Drive shaft: Ф58mm

Motor power: 37KW

Power supply voltage: 380V 50-60HZ

Dimensions: 2350 × 1560 × 1160mm

Third, the automatic straightening machine equipment performance:

A. Straighten the way straight line straight continuous operation

B. Straightening range pipe ф28-89mm * T3..0mm. Bar ф28-50mm

C. Straightening length of 2 meters -15 meters

D. Operating speed frequency control speed 0-40m / min

A Straightening accuracy ≤ 0.3mm / m

Fourth, straightening machine structure:

A. Motor power: 15KW B. Inverter: 18KW. Drive shaft: Ф58 mm D. Roller: Ф120 × 150 14 groups

?A Center High: 920mm F. Weight: 5000kg I. Power supply voltage: 380V 50-60HZ

?F. Dimensions: 2350 × 1560 × 1160

?G. Handwheel conditioning: digital display shows the movement interval, hand wheel rotation of the week, the wheel moving 1mm
